# How to Sort by Geo Distance Using Bounding Boxes in Algolia

Under the hood of an app I'm helping build, we utilize Algolia for search results. One of the features we support are to show items outside the user's search radius.

For example, let's say you were looking for an item to buy within 30 miles of you. But it so happens that the perfect item is listed 31 miles from you. In this case, we'll show you a module with items outside your search radius (e.g. 30-50 miles).

We'll define the problem concretely.

Let `radius` be the radius from the user to the item. Let `min_radius` and `max_radius` be the minimum/maximum radius to search within. We need to search for items where `min_radius < radius < max_radius`.

## Limitations of Algolia Geo Filters

As of the time of writing, Algolia has no native way to solve such a problem.

The only way to get geo-sorting is by using their `aroundRadius` parameter, but this param doesn't support a `min_radius` param.

We also considered using Algolia's `insideBoundingBox` parameter, which lets us specify multiple boxes to search within. We could support the area where `min_radius < radius < max_radius` by constructing 4 boxes around the inner bounding box. However,

`aroundLatLng` will be ignored if used along with this parameter.

This means we wouldn't be able to support our "sort by closest items first" use case. This is a non-starter.

We could've worked around this limitation by changing the client. But being that our business is centered around our mobile app, the client code is already deployed across many customers' devices.

We need to be able to make this change server-side to stay nimble.

## Using Numeric Filters to Create Bounding Boxes

To support geo-sorting, Algolia expects documents to contain a `_geoloc` property specifying the coordinates.

For example, an item document would contain something like the following:

``````{
"_geoloc": {
"lat": 47.6062,
"lng": -122.3321
}
}
``````

With this available, we're able to configure the index to allow `_geoloc.lat` and `_geoloc.lng` to be used as numeric filters to create our own filtering logic.

To sort by distance, we can combine `aroundLatLng` and `aroundRadius`. The radius we define will surround the bounding boxes we create using numeric filters on `_geoloc.lat` and `_geoloc.lng`.

### Implementation Details

Let's recall the problem: We want to search for items where the item's `radius` is between some `min_radius` and `max_radius`.

Here's how we can solve it:

• Set `aroundLatLng` to the user's location.
• Set `aroundRadius` to `"all"`. We need the radius to surround the bounding boxes we create.
• Create bounding boxes by filtering on `_geoloc.lat` and `_geoloc.lng`.

Let's see what this looks like in practice.

We'll show all items within a bounding box. Let's assume you've done some logic to compute the coordinates of the upper-left and bottom-right points of the bounding box.

``````index.search('query', {
aroundLatLng: '47.6062, -122.3321',
filters: [
`_geoloc.lat < \${upperLeft.lat}`,
`_geoloc.lat > \${bottomRight.lat}`,
`_geoloc.lng > \${upperLeft.lng}`,
`_geoloc.lng < \${bottomRight.lng}`,
].join(' AND '),
});
``````

This is a start.

Now we want to filter out the items that are contained within an inner bounding box.

In other words, let's call the outer bounding box `withinOuterBoundingBox` and the inner bounding box `withinInnerBoundingBox`. We want to search the items that satisfy

``````withinOuterBoundingBox && !withinInnerBoundingBox;
``````

We already saw above how to search within the outer bounding box.

``````const withinOuterBoundingBox = [
`_geoloc.lat < \${upperLeft.lat}`,
`_geoloc.lat > \${bottomRight.lat}`,
`_geoloc.lng > \${upperLeft.lng}`,
`_geoloc.lng < \${bottomRight.lng}`,
].join(' AND ');
``````

You might think we could negate a similar filter for the inner bounding box:

``````NOT (A AND B AND C AND D)
``````

However, Algolia doesn't let us create a filter like this.

You can verify filter syntax with Algolia's filter syntax validator.

We can workaround this limitation by distributing the `NOT` using De Morgan's Law. The following is logically equivalent and valid filter syntax:

``````NOT A OR NOT B OR NOT C OR NOT D
``````

We wouldn't use the `NOT` syntax since we're dealing with numeric filters.

In order to negate an inequality, we need to flip the sign.

• `<` becomes `>=`
• `>` becomes `<=`

We can now piece together an expression to exclude the inner bounding box.

``````const notWithinInnerBoundingBox = [
`_geoloc.lat >= \${innerBoxUpperLeft.lat}`,
`_geoloc.lat <= \${innerBoxBottomRight.lat}`,
`_geoloc.lng <= \${innerBoxUpperLeft.lng}`,
`_geoloc.lng >= \${innerBoxBottomRight.lng}`,
].join(' OR ');
``````

Putting this all together, our Algolia query becomes:

``````index.search('query', {
aroundLatLng: '47.6062, -122.3321',
filters: `\${withinOuterBoundingBox} AND \${notWithinInnerBoundingBox}`,
});
``````

And that's how we solved this problem. ๐

## Bonus: Performance Considerations of Setting `aroundRadius` to `"all"`

I was concerned that setting `aroundRadius` to `"all"` would degrade performance.

We did some performance tests comparing the results of setting `aroundRadius` to `"all"` versus the minimum radius that surrounds the outer bounding box.

It didn't make much of a difference.

To keep things simple, you're probably fine setting `aroundRadius` to `"all"` when using `_geoloc` to filter results.
